Europe Warehouse Stock High Efficiency All Black roof Solar Panel 435W 440W 450W 144 Cells Half Cell Black Panels Solar

Europe Warehouse Stock High Efficiency All Black roof Solar Panel 435W 440W 450W 144 Cells Half Cell Black Panels Solar

Inquiry
  • Overview
  • Inquiry
  • Related Products
Product Description

166mm&182mm

Mono ALL BLACK

*Full Black Appearance for Aesthetic Effect
*Gallium-doped Technology
*Half Cut Cell Technology
*Anti-PID&Low-LID Performance
*Less Hot Spot Shading Effects
*Ideal for Residential&Commercial Application
Electrical Data
166mm Series(STC)
Model
LS166 360-375W HB
LS166 395-410W HB
LS166 435-450W HB
Numbers of solar cells
120(60*2)
132(66*2）
144(72*2)
Power Tolerance
0~+5W
Maximum power range(Pmax)
360W-375W
395W-410W
435W-450W
Open Circuit Voltage (Voc)
40.79V-41.37V
45.56V-46.23V
49.4V-49.98V
Short Circuit Current (Isc)
11.18A-11.42A
11.19A-11.39A
11.36A-11.54A
Voltage at Maximum power (Vmpp)
33.71V-34.34V
36.93V-37.64V
40.81V-41.4V
Current Maximum Power (Impp)
10.68A-10.92A
10.70A-10.89A
10.66A-10.87A
MODULE EFFICIENCY (%)
19.73-20.55
19.75-20.5
19.98-20.67
182mm Series(STC)
Model
LS182 485-500W HB
LS182 530-545W HB
LS182 575-590W HB
Numbers of solar cells
132(66*2）
144(72*2)
156(78*2)
Power Tolerance
0~+5W
Maximum power range(Pmax)
485W-500W
530W-545W
575W-590W
Open Circuit Voltage (Voc)
48.34V-48.83V
49.74V-50.18V
50.45V-51.02V
Short Circuit Current (Isc)
12.99A-13.2A
13.62A-13.83A
14.41A-14.57A
Voltage at Maximum power (Vmpp)
40.08V-40.62V
41.63V-42.12V
43.04V-43.48V
Current Maximum Power (Impp)
12.10A-12.31A
12.73A-12.94A
13.36A-13.57A
MODULE EFFICIENCY (%)
20.42-21.06
20.51-21.09
20.57-21.11

STC: Irradiance 1000W/m², cell temperature 25ºC,AM1.5G
Temperature Ratings ( STC )

Temperature Coefficient of Isc
 +0.05%/C
Temperature Coefficient of Voc -0.28%/C

Temperature Coefficient of Pmax
-0.36%/C


Mechanical Loading

Front Side Maximum Static Loading 5400Pa Rear Side Maximum Static Loading 2400Pa Operating Module Temperature -40ºC to + 85ºC
Our Technology
Half-Cut Cell + Twin Panel Technology
Half-cut cell + twin panel technology consists in cutting the solar cell in half by non destructive cutting infrared laser and splits the conventional layout of 3 cell-strings in 1 electric circuit into the innovative layout of 6 cell-strings + 2 electric circuits in a PV module.
This technology halves the electric current of the cell and reduces effectively the internal electric resistance on the cell ribbon and increases the module power by 2%. The twin panel design minimizes the power loss in shading conditions, hence improves the system mismatch and heightens the efficiency of the PV system.

Lower Hot Spot Temperature

By halving the electric current of both the cells and the cell-strings, the hot spot temperature can be reduced by 50%, which enhances the reliability of the PV module.


Lower Shading Loss

The twin section layout of the cell strings in a PV module enables the module to continue to produce at least 50% of the overall energy even when one part of the module or the cell string is shaded.
Multi-busbar Technology
In comparison with the conventional 5 busbar design, the innovative multi-busbar design on the cell can shorten the current collection transverse path by 50% and thereby reduce remarkably the cell internal resistance, which contributes a 1% - 1.5% increase in the power output compared with 5 busbar design.
The MBB design can also mitigate the performance loss caused by blocked electrical pathways in case of cell microcracks and finger electrode erosion due to external factors.
Another advantage of the MBB design is the improved light absorption thanks to the round ribbon application. In comparison with the traditional flat ribbon of 5BB, the round ribbon can increase the light utilization by 1% - 1.5%.
Details Images
EVA Sealed Film
*Top quality EVA sealed film in China *Resistance in both high and low temperatures
*Sealed adhesive durability more than 30 years


Laser Half Cut Cell
*Solid PID resistance ensured by solar cell
*process optimization and careful module BOM selection
*Laser accurately cut
* Both 6BB&9BB available

Junction Box
*Standard photovoltaic cable, dedicated photovoltaic MC4 connector
*Waterproof grade IP68
*Good heat dissipation performance, low loss, long service life

Black aluminum frame
Heavy thickness anodized aluminum alloy, passed the salt spay test, for long-term outside use.

Black backsheet
It protects and supports the solar cells, with reliable insulation, water resistance, and aging resistance
Quality Control
RAW MATERIAL MANAGEMENT
Stringent supplier management
Automatic material filtration and sorting
Manual standard sampling inspection by batch.
Constant temperature and humidity storage environment.
Supplier Quality Engineering
Incoming-material quality assurance


PRODUCTION MANAGEMENT
Quality monitoring of the whole production line
Multiple EL tests
Mobile sampling inspection


FACTORY INSPECTION
Test results are entered into the database in real time.
Simulating open-box testing
Spot check every feedstock batch
Pack&shipping
Model
LS166 360-375W HB
LS166 395-410W HB
LS166 435-450W HB
Pieces per pallet
31Pieces
31Pieces
31Pieces
20'GP Container
186Pieces/6pallet
186Pieces/6pallet
155Pieces/5pallet
40'HQ Container
806Pieces/26pallet
744Pieces/24pallet
682Pieces/22pallet
Model
LS182 485-500W HB
LS182 530-545W HB
LS182 575-590W HB
Pieces per pallet
31Pieces
31Pieces
31Pieces
20'GP Container
155Pieces/5pallet
155Pieces/5pallet
124Pieces/4pallet
40'HQ Container
682Pieces/22pallet
620Pieces/20pallet
496Pieces/16pallet
