Product Description
Specifications
Model |
SUN-5K-SG01LP1
-US/EU
|
SUN-7.6K-SG01LP1-EU |
SUN-8K-SG01LP1
-US/EU
|
Battery Input Data | |||
Battery Type |
Lead-acid or Lithium-ion |
||
Banery Voltage Range (V) |
40-60V |
||
Max. Charging Current (A) |
120A |
190A |
190A |
Max. Discharging Current (A) |
120A |
190A |
190A |
Charging Curve |
3 Stages / Equalization |
||
External Temperature Sensor |
Optional |
||
Charging Strategy for Li-Ion Battery |
Self-adaption to BMS |
||
PV String Input Data | |||
Max. DC Input Power (W) |
5500W |
9880W |
8800W |
PV Input Voltage (V) |
500V |
370V (100V 〜500V) |
500V |
MPPT Range (V) |
125V-425V |
||
Start-up Voltage (V) |
150V |
||
PV Input Current (A) |
10A+10A |
22A+22A |
18A+9A |
No.of MPPT Trackers |
2 |
||
No.of Strings Per MPPT Tracker |
1\1 |
2+2 |
2\1 |
AC Output Data | |||
Rated AC Output and UPS Power (W) |
5000W |
7600W |
8000W |
Peak Power (off grid) |
2 times of rated power, 10 S |
||
Max. AC Current (A) |
20.8A |
36.3A |
33A |
Output Frequency and Voltage |
50/60Hz; 120Vac&240Vac(split phase), 230Vac(single phase) |
50 / 60Hz; 23(Vac (single phase) |
50/60Hz; 120Vac&240Vac(split phase), 230Vac(single phase) |
Grid Type |
Single Phase |
||
Current Harmonic Distortion |
THD<3% (Linear load<1.5%) |
||
Efficiency | |||
Max. Efficiency |
97.60% |
||
Euro Efficiency |
97.00% |
||
MPPT Efficiency |
99.90% |
||
Certifications and Standards | |||
Grid Regulation |
VDE 0126, AS4777, NRS2017, G98, G99, IEC61683, IEC62116JEC61727 |
||
Safety Regulation |
IEC62109-1, IEC62109-2 |
||
EMC |
EN61000-6-1, EN61000-6-3, FCC 15 class B |
||
General Data | |||
Operating Temperature Range (°C) |
-25-~60°C, >45°C Derating |
||
Cooling |
Smart cooling |
||
Noise (dB) |
<30 dB |
||
Communication with BMS |
RS485; CAN |
||
Weight (kg) |
32 |
||
Size (mm) |
680*420*233mm |
||
Protection Degree |
IP65 |
||
Installation Style |
Wall-mounted |
||
Warranty |
5 years |
||
