Single Phase Growatt 5kw Hybrid Solar Inverter 48V Solar Hybrid Inverter Pure Sine Wave Off Grid Inverter for Solar System
- Overview
- Inquiry
- Related Products
lovsun
Launching the Solitary Stage Growatt 5kw Crossbreed Solar Inverter 48V Solar Crossbreed Inverter Natural Sine Wave Off Grid Inverter for Solar Body, these gadgets enhance ideal solar innovation body. By utilizing this revolutionary product, you can easily enhance your solar innovation utilize as well as expertise and easy however efficient as well as source of power lasting.
The Solitary Stage Growatt 5kw Crossbreed Solar Inverter 48V Solar Crossbreed Inverter Natural Sine Wave Off Grid Inverter for Solar Body was created along with premium innovation towards source efficiency exceptional. It is a Solar Crossbreed 48V that integrates together with your solar body, creating specific every drop of sunlight to become energy. The inverter was produced to endure the severe environment, guaranteeing you energy continuous every period.
The Solitary Stage Growatt 5kw Crossbreed Solar Inverter 48V Solar Crossbreed Inverter Natural Sine Wave Off Grid Inverter for Solar Body is simply a Natural Sine Wave Off-Grid Inverter, which implies that it might potentially be an inverter on-grid furthermore an energy back-up the vigor grid drops. It is an innovation to a greater degree that enables you to benefit from your solar body efficiently while furthermore possessing a back-up energy source in the event of emergency situations.
The Solitary Stage Growatt 5kw Crossbreed Solar Inverter 48V Solar Crossbreed Inverter Natural Sine Wave Off Grid Inverter for Solar Body is simple to set up, proceed preserving, as well as operate. Along edge its own easy to use course, it truly is easy towards screen as well as get command of your power solar body. It provides a high-resolution screen and a variety of built-in functions that improve its own efficiency.
Among the much a lot better great factors for the Solitary Stage Growatt 5kw Crossbreed Solar Inverter 48V Solar Crossbreed Inverter Natural Sine Wave Off Grid Inverter for Solar Body is its own scalability. It might be scaled up or even appropriate to suit your energy requirements, making it effectively fit for each residential as well as industrial solar power. Along with the inverter, you will have the ability to include much a lot of extra boards being solar an individual's body system as well as luxuriate in much less power cost.
|
Datasheet
|
SPH3000
|
SPH4000
|
SPH4600
|
SPH5000
|
SPH6000
|
|||||
|
PV Input data
|
||||||||||
|
Max. recommended PV power (for module STC)
|
6000W
|
8000W
|
9200W
|
10500W
|
11200W
|
|||||
|
Max. DC voltage
|
550V
|
|||||||||
|
Start voltage
|
120V
|
|||||||||
|
MPP voltage range
|
120V-550V/360V
|
|||||||||
|
No. of MPP trackers
|
2
|
|||||||||
|
No. of PV strings per MPP tracker
|
1
|
|||||||||
|
Max. input current per MPP tracker
|
13.5A
|
|||||||||
|
Max. short-circuit current per MPP tracker
|
16.5A
|
|||||||||
|
AC Output
|
||||||||||
|
Rated AC output power
|
3000W
|
4000W
|
4600W
|
5000W
|
6000W
|
|||||
|
Max. AC apparent power
|
3000VA
|
4000VA
|
4600VA
|
5000VA
|
6000VA
|
|||||
|
Nominal AC voltage (range)
|
230V/（180Vac-270Vac)
|
|||||||||
|
AC grid frequency (range)
|
50Hz/60Hz (45Hz-55Hz/55Hz-65Hz)
|
|||||||||
|
Max. output current
|
16A
|
22A
|
22A
|
22A
|
27A
|
|||||
|
AC grid connection type
|
Single phase
|
|||||||||
|
AC output power(Backup)
|
||||||||||
|
Max. output power
|
3000W
|
3000W
|
3000W
|
3000W
|
3000W
|
|||||
|
Max. output current
|
17.4A
|
|||||||||
|
Rated AC output voltage
|
230Vac
|
|||||||||
|
Rated AC output frequency
|
50/60Hz
|
|||||||||
|
THDv
|
<3%<>
|
|||||||||
|
Switch time
|
<10ms
|
|||||||||
|
Battery data
|
||||||||||
|
Battery voltage range
|
42~59V
|
|||||||||
|
Max charging and discharging current
|
66A
|
85A
|
85A
|
85A
|
85A
|
|||||
|
Max charging and discharging power
|
3000W
|
4000W
|
4000W
|
4000W
|
4000W
|
|||||
|
Type of battery
|
Lithium /Lead-acid
|
|||||||||
|
MPPT efficiency
|
≥99.5%
|
|||||||||
|
General data
|
||||||||||
|
Dimensions (W / H / D)in mm
|
458/565/188mm
|
|||||||||
|
Weight
|
31kg
|
|||||||||
|
Operating temperature range
|
-25°C... +60°C
|
|||||||||
|
Protection degree
|
IP65
|
|||||||||
|
PV DC Connection
|
MC4/H4(opt)
|
|||||||||
|
Interface:RS232/USB/RF/Wi-Fi
|
yes/yes /opt/opt
|
|||||||||
|
Interfaces:RS485/CAN/USB
|
Yes
|
|||||||||
|
Monitor : RF/WIFI/GPR
|
Optional
|
|||||||||
|
Warranty: 5 years /10 years
|
yes / opt
|
|||||||||
