144 CELLS Mechanical Specifications |
||
External Dimensions |
2094 x 1038 x 35 mm |
|
Weight |
23.5kg |
|
Solar Cells |
PERC Mono 166 x 83mm (144pcs) |
|
Model Number |
440W |
445W |
450W |
455W |
||||||||||||
Testing Condition |
STC |
NOCT |
STC |
NOCT |
STC |
NOCT |
STC |
NOCT |
||||||||
Maximum Power (pmax/W) |
440 |
328.6 |
445 |
332.3 |
450 |
336.1 |
455 |
339.8 |
||||||||
Open Circuit Voltage (Voc/V) |
48.9 |
45.8 |
49.1 |
46.0 |
49.3 |
46.2 |
49.5 |
46.4 |
||||||||
Short Circuit Current (Isc/A) |
11.46 |
9.27 |
11.53 |
9.33 |
11.60 |
9.38 |
11.66 |
9.43 |
||||||||
Voltage at Maximum Power (Vmp/V) |
41.1 |
38.3 |
41.3 |
38.5 |
41.5 |
38.6 |
41.7 |
38.8 |
||||||||
Current at Maximum Power (Imp/A) |
10.71 |
8.59 |
10.78 |
8.64 |
10.85 |
8.70 |
10.92 |
8.75 |
||||||||
Module Efficiency (%) |
20.2 |
20.5 |
20.7 |
20.9 |
||||||||||||
STC (Standard Testing Conditions): Irradiance 1000W/㎡, Cell Temperature 25℃, Spectra at AM1.5 |
||||||||||||||||
NOCT (Nominal Operating Cell Temperature): Irradiance 800W/㎡, Ambient Temperature 20℃, Spectra at AM1.5, Wind at 1m/s |
||||||||||||||||
120 CELLS 375-380w Mechanical Specifications |
||
External Dimensions |
1755 x 1038 x 35 mm |
|
Weight |
19.5kg |
|
Solar Cells |
PERC Mono (120pcs) |
|
Mono Half Cut Cell
EVA Sealed Film
Aluminum frame
Junction Box
Compatible MC4 Connectors
Label
Payment Terms
|
T/T
|
EXW |
30% in advance for deposit payment, the balance payments will be paid before shipment. |
||||
FOB |
|||||||
CFR/C&F |
30% in advance for deposit payment, the balance will be paid against copy of B/L |
||||||
CIF |
|||||||
L/C |
For the amount of one shipment above 50,000 usd, L/C at sight is acceptable. |
||||||
West Union |
For the amount less than 5000 usd |
||||||
Paypal |
|||||||
Delivery Time |
7~25 days after receiving the payment or the deposit payment |
||||||
We recommend you use alibaba Insurance Order Online, you will enjoy
The third party inspection is optional
Lovsun
Introducing Mono Half Cell Solar Panels, the perfect solution for all your energy needs. With choices ranging from 450w to 550w, you can easily find the right size for your home or workplace. Additionally, you can pair various sizes to create a system that fits your exact requirements.
Our 450w 480w 500w 550w lovsun Mono Half Cell Solar Panel 1000w Price 600-Watt Pv Module ps are created using the quality materials greatest and technologies, which ensures maximum efficiency and durability. Offer an increased cell thickness with half-cut cells and shading is superior to increase efficiency, and darker color to enhance aesthetics. Produced from tempered glass and anodized aluminum which provides protection against harsh weather, hail, and snow.
You can save money, which allows you to power your daily activities and have now enough energy supply during power outages. With this panels, you can create electricity during the and this can be stored in batteries, and used during the night if you have no sunlight time. This can lead to power is significant cost savings and protection against power shortages.
Thanks to state-of-the-art technology, our panels are easy to put in, and our team is professional can with you to install your entire system. Furthermore, our panels come with pre-drilled holes, making installation on any surface an easy and task is simple.
At Lovsun, we have been focused on power is solar and eco-friendliness. We offer pricing is competitive our products without compromising on quality, and we provide excellent after-sale service to ensure that your panels work optimally. Our Lovsun 450w 480w 500w 550w Lovsun Mono Half Cell Solar Panel 1000w Price 600-Watt Pv Module.
Try Lovsun Mono Half Cell Solar Panel today and discover a better way to power your homes or businesses.
